HDD machine for sale, short for horizontal directional drilling machine, is a trenchless drilling technique used to install underground infrastructure without disrupting surface activities. Unlike traditional open-cut methods, HDD involves drilling a pilot bore along a predetermined path, followed by reaming to enlarge the hole and finally pulling the pipeline or conduit into place. This method minimizes environmental impact, reduces restoration costs, and allows installations beneath obstacles like rivers, highways, and urban landscapes.
Technical Data of HDD Machine For Sale
| Model | YG-50LS | YG-130LS | YG-150LS | YG-200LS |
| Weight | 3650kg | 4750kg | 4700kg | 8800kg |
| Max. Thrust & Pullback Force | 51kN | 135kN | 150kN | 205kN |
| Max. Torque | 2235N·m | 4500N·m | 4500N·m | 6500N·m |
| Engine Power | 43kw | 93kw | 93kw | 113kw |
| Walking Speed | 2.5km/h | 2.5-4.5km/h | 2.5-4.5km/h | 2.5-4km/h |
| Entry Angle | 14°-17° | 12°-22° | 12°-22° | 12°-22° |
| Drill Rod Size | φ42*1800mm | φ50/φ60*3000mm | φ60*2000mm | φ60*3000mm |
| Suggest Reaming Diameter | ≤φ400mm | ≤φ700mm | ≤φ700mm | ≤φ800mm |
| Dimension(L*W*H) | 3870*1300*1470mm | 5470*1670*2040mm | 4200*1700*2140mm | 6750*2050*2400mm |
| Max. Thrust & Pullback Speed | 61m/min | 36m/min | 46m/min | 60m/min |
| Max. Rotation Speed | 215r/min | 193r/min | 193r/min | 230r/min |
| Max. Mud Flow | 75L/min | 200L/min | 180L/min | 250L/min |
| Max. Mud Pressure | 6Mpa | 8Mpa | 8Mpa | 8Mpa |
| Max. Climbing Gradient | 17° | 16° | 17° | 17° |
| Drill Rod Box Capacity | 44pcs(4*11) | 48pcs(4*12) | 56pcs(4*14) | 48pcs(4*12) |
| Suggest Crossing Length | ≤100m | ≤200m | ≤200m | ≤300m |
Components of HDD Machine For Sale
- Drill Rig
This is the core of the HDD system, housing the engine, rotary drives, and hydraulic systems that provide the thrust and rotation for drilling operations. - Drill Rods and Drill Bits
The rods connect to the drill bit and are added as the bore progresses. Different types of bits are used depending on the ground conditions, such as clay, sand, or rock. - Mud System
HDD machine use drilling fluid (typically a mixture of water and bentonite) to cool the bit, remove cuttings, and stabilize the borehole. - Tracking and Guidance System
This ensures that the drill follows the designed path. Modern systems use electromagnetic fields or gyroscopes for accurate positioning. - Reamer and Pullback Assembly
Once the pilot hole is completed, it is enlarged using a reamer before the final pipe or conduit is pulled back through the borehole.
Applications of Horizontal Directional Drilling Rig
- Utility Installations
HDD is ideal for installing fiber optic cables, electrical conduits, water lines, and natural gas pipelines. Its ability to navigate around existing infrastructure makes it indispensable in densely populated areas. - Environmental Projects
HDD machine for sale minimizes ecosystem disruption when crossing sensitive habitats, wetlands, or water bodies. For example, it is frequently used to install pipelines beneath rivers without affecting aquatic life. - Oil and Gas Industry
Horizontal directional drilling machine drill underground pathways for oil and gas pipelines, particularly in regions where surface drilling is impractical or environmentally risky.
How to Choose the Right HDD Machine？
When exploring options for an HDD Machine For Sale, there are several factors to consider to ensure you select the right equipment for your needs.
- Project Scope and Requirements
Evaluate the size and type of projects you usually handle. Small urban jobs may only require a mini HDD rig, while pipeline installations over long distances may demand more powerful systems. - Ground Conditions
Some machines are better suited for soft soil, while others are built to drill through rock. Make sure the model you choose is compatible with your common ground conditions. - Pullback Force and Torque
These are the two primary metrics of an HDD machine’s performance. Higher pullback force and rotational torque allow the machine to handle larger diameter pipes and longer bores.
